Minisart® Syringe Filter, Polytetrafluorethylene (PTFE), Pore Size 0.45 µm, Non-Sterile, Male Luer Slip, Male Luer Slip, Pack Size 500

Tech Support Documents Submit Review
Minisart® Syringe Filter, Polytetrafluorethylene (PTFE), Pore Size 0.45 µm, Non-Sterile, Male Luer Slip, Male Luer Slip, Pack Size 500


Minisart® Acticosart with chemically inert hydrophobic PTFE is suitable for venting as well as filtration of gases with a pH of 3 - 12. Type 17840 has a 0.45 µm PTFE and a reservoir with active carbon. It can be used for venting and adsorption of substances. It has a male luer slip inlet and outlet. Version Q is a non-sterile bulk pack. Units can be sterilized by EO.

Price (CNY):
CNY18,632.56
Item No.:
17840----------Q
Availability:
Pieces
500

*Custom/bulk order quotes are provided within 24 hours of request.

Choose your Minisart® with Acrylic-based MBS Housing

See more products

Non-sterile Minisart® Acticosart syringe filters are supplied in bulk packs. This reduces waste and makes the handling easier whenever the application allows venting under non-sterile conditions. Due to its hydrophobic nature the PTFE membrane functions as a water barrier and does not become wetted by aerosols. This keeps the hydrophobic venting filter permeable for gas or air! The active carbon filling adsorbs molecules, e.g. unpleasant smell resulting from polymerisation reactions. The housing of the filter is made of MBS (Methacrylate butadiene styrene) which has a limited compatibility with alcohols but is free of phthalates and passes the plastic class VI test. It is glueable, e.g. to tubing, what enables assembly and sterilization by the user.

  • Bulk packs for less waste
  • PVC-free
  • Active carbon filling
  • Glueable, e.g. to tubing

Applications

  • Application
    Ultracleaning of air and gases
  • Application Area
    • Venting
    • Moisture barrier

Connections (Physical)

  • Connector Inlet
    Male Luer Slip
  • Connector Outlet
    Male Luer Slip

Dimensions

  • Filter Diameter
    ⌀ 26 mm
  • Filtration Area
    5.3 cm²

Features

  • High Flow
    No

General Specifications

  • Filter Paper/Membrane Color
    Clear/Blue
  • Flow Rate
    ≥ 2300 mL/min for air at 0.1 bar (1.5 psi)
  • pH Range
    4.0 – 8.0

Materials of Construction

  • Housing Material
    Methacrylate butadiene styrene (MBS)
  • Material Prefilters
    Active Carbon
  • Membrane Material
    Polytetrafluorethylene (PTFE)

Operating Conditions

  • Maximum Allowable Working Temperature
    60 °C (140 °F)
  • Maximum Operating Pressure
    1 bar (14.5 psi)
  • Operating Pressure
    1 bar (14.5 psi)

Physicochemical Information

  • Bubble Point
    ≥ 0.9 bar (13 psi) with ethanol
  • Burst Pressure
    ≥ 7.0 bar (102 psi)
  • Pore Size
    0.45 µm
  • Wettability
    Hydrophobic

Product Information

  • Brand
    Minisart® Acticosart
  • Device Type
    Syringe Filters
  • Pack Size
    500
  • Packaging
    Bulk packed
  • Sample Type
    Air/Gas

Sterility/Purity

  • Delivery Condition
    Non-Sterile
  • Sterilization Method
    Ethylene oxide

Volume

  • Hold-up Volume
    ≤ 100 – 150 µL
