Sartolon

Tech Support
Sartolon

Sartolon filters are designed for broad chemical compatibility for specific applications in the pharmaceutical and chemical industry. The double-layer design leads to superior filtration performance compared to other nylon membrane filters and thereby allows more economical design of your filtration process. Sartolon filter elements are ideal for filtration of a broad range of solvents and solvent-containing liquids as well as oily formulations.
Availability:
See more Products below
*Custom/bulk order quotes are provided within 72 hours of request.
Sartolon
Sartolon
Sartolon filters are designed for broad chemical compatibility for specific applications in the pharmaceutical and chemical industry. The double-layer design leads to superior filtration performance compared to other nylon membrane filters and thereby allows more economical design of your filtration process. Sartolon filter elements are ideal for filtration of a broad range of solvents and solvent-containing liquids as well as oily formulations.
Item No.:
M_Sartolon
Availability:

Overview

Specifications

Choose your product

Filter by product attributes

Products (20)

  • Sartolon | 0.2 µm | Sartoscale (PD | Material Screening)
    Documents
    Sartolon | 0.2 µm | Sartoscale (PD | Material Screening)
    Item no.
    5105307HV--LX--C
    Filter Size
    4.5 cm²
    Connector(s)
    Inlet: Female Luer | Outlet: Male Luer
    Pack Size
    6
    Item no.
    5105307HV--LX--C
    Filter Size
    4.5 cm²
    Connector(s)
    Inlet: Female Luer | Outlet: Male Luer
    Pack Size
    6
    Item no.
    5105307HS--FF--M
    Filter Size
    17.3 cm²
    Connector(s)
    Inlet: ¾" Sanitary | Outlet: ¾" Sanitary
    Pack Size
    3
  • Sartolon | 0.2 µm | Maxicaps® (Production | Large Scale)
    Documents
    Sartolon | 0.2 µm | Maxicaps® (Production | Large Scale)
    Item no.
    5107307H1--SO
    Filter Size
    10"(0.6 m² / 6.5 ft²)
    Connector(s)
    Inlet: 1 ½" Sanitary | Outlet: ½" Hose Barb
    Vent Valve
    Standard
    Item no.
    5107307H1--SO
    Filter Size
    10"(0.6 m² / 6.5 ft²)
    Connector(s)
    Inlet: 1 ½" Sanitary | Outlet: ½" Hose Barb
    Vent Valve
    Standard
    Item no.
    5107307H1--SS
    Filter Size
    10"(0.6 m² / 6.5 ft²)
    Connector(s)
    Inlet: 1 ½" Sanitary | Outlet: 1 ½" Sanitary
    Vent Valve
    Standard
    Item no.
    5107307H1--OO
    Filter Size
    10"(0.6 m² / 6.5 ft²)
    Connector(s)
    Inlet: ½" Hose Barb | Outlet: ½" Hose Barb
    Vent Valve
    Standard
  • Sartolon | 0.2 µm | Cartridge
    Documents
    Sartolon | 0.2 µm | Cartridge
    Item no.
    5102507H1
    Filter Size
    10"(0.6 m² / 6.5 ft²)
    Material o-ring | seal
    Silicone (SI)
    Adapter
    Bottom: 2-Flange Bayonet w. 226 double o-ring | Top: S-Adapter
    Item no.
    5102507H1
    Filter Size
    10"(0.6 m² / 6.5 ft²)
    Material o-ring | seal
    Silicone (SI)
    Adapter
    Bottom: 2-Flange Bayonet w. 226 double o-ring | Top: S-Adapter
    Item no.
    5102507H2
    Filter Size
    20"(1.2 m² / 12.9 ft²)
    Material o-ring | seal
    Silicone (SI)
    Adapter
    Bottom: 2-Flange Bayonet w. 226 double o-ring | Top: S-Adapter
    Item no.
    5102507H3
    Filter Size
    30"(1.8 m² / 19.4 ft²)
    Material o-ring | seal
    Silicone (SI)
    Adapter
    Bottom: 2-Flange Bayonet w. 226 double o-ring | Top: S-Adapter
  • Sartolon | 0.2 µm | Midicaps® (Production | Small Scale)
    Documents
    Sartolon | 0.2 µm | Midicaps® (Production | Small Scale)
    Item no.
    5105307H9--SS--A
    Connector(s)
    Inlet: 1 ½" Sanitary | Outlet: 1 ½" Sanitary
    Item no.
    5105307H9--SS--A
    Connector(s)
    Inlet: 1 ½" Sanitary | Outlet: 1 ½" Sanitary
    Item no.
    5105307H9--SO--A
    Connector(s)
    Inlet: 1 ½" Sanitary | Outlet: ½" Hose Barb
    Item no.
    5105307H9--OO--A
    Connector(s)
    Inlet: ½" Hose Barb | Outlet: ½" Hose Barb
Results per page: | |

Sterilizing-Grade, 0.2 µm Rated Filters

Sartolon Pore size: 0.45 | 0.2 µm (heterogeneous Polyamide double layer)

Your Benefits:

  • High chemical compatibility for the filtration of solvents e.g. in ADC process
  • High filter capacity by in-built pre-filter (double-layer construction)
  • Excellent performance for oily formulations
  • Highly economic solution e.g. for antibiotics processes

Sartolon filters are not suitable for gamma irradiation. For easy integration of non-gamma filters into single-use assemblies, we offer a wide range of possibilities with our Filter Transfer Set solutions. For highest process flexibility Sartolon filters are available for conventional stainless-steel or single-use applications.The filter elements are available in various sizes and connector combinations. Please review the selection guide in the supporting literature.
