Name: CIMac
Brand: Sartorius
SKU: M_CIMac
Availability: OutOfStock

CIMac Analytical Columns combine all elaborate characteristics of CIM^® monoliths at analytical scale and are your perfect tool for analysis and control of manufacturing processes, ideal for process analytical technology (PAT).

Designed for fast and reproducible HPLC monitoring and quantitation of proteins, viruses, pDNA, and other large biomolecules, they allow you to achieve rapid, high-resolution and flow-independent separations in a matter of minutes.

See more Products below

*Custom/bulk order quotes are provided within 72 hours of request.

CIMac

Item No.:

M_CIMac

Products (25)

CIMac SO3 Analytical Columns

Documents
Channel Size:
Item no.

110.6157-1.3

Channel Size

1.3 µm

Item no.

110.6157-1.3

Channel Size

1.3 µm

Item no.

110.6157-2

Channel Size

2 µm

Item no.

110.6157-6

Channel Size

6 µm
CIMac OH Analytical Columns
Channel Size:
Item no.

110.8140-1.3

Channel Size

1.3 µm

Item no.

110.8140-1.3

Channel Size

1.3 µm

Item no.

110.8140-2

Channel Size

2 µm

Item no.

110.8140-6

Channel Size

6 µm
CIMac QA Analytical Columns

Documents
Channel Size:
Item no.

110.5113-1.3

Channel Size

1.3 µm

Item no.

110.5113-1.3

Channel Size

1.3 µm

Item no.

110.5113-6

Channel Size

6 µm
CIMac EDA Analytical Columns

Documents
Channel Size:
Item no.

110.5116-1.3

Channel Size

1.3 µm

Item no.

110.5116-1.3

Channel Size

1.3 µm
CIMac pDNA Analytical Columns
Channel Size:
Item no.

150.8501-1.4

Channel Size

1.4 µm

Item no.

150.8501-1.4

Channel Size

1.4 µm

Item no.

150.8501-6

Channel Size

6 µm
CIMac Oligo dT18 0.1 mL Analytical Column (C12 Linker) (2 µm)

Documents
Ligand:

Oligo dT18 coupled to CDI-activated matrix, C12 Linker
Bed Volume:

0.1 mL
Channel Size:

2 µm
Item no.

110.1219-2

Item no.

110.1219-2
CIMac XY 0.1 mL Analytical Column (1.3 µm)

Documents
Ligand:

XY (activated; epoxy)
Bed Volume:

0,1 mL
Channel Size:

1.3 µm
Item no.

110.7175-1.3

Item no.

110.7175-1.3
CIMac Adeno 0.1 mL Analytical Column (2 µm)
Ligand:

QA modified for Adeno (strong anion exchanger, quaternary amine)
Bed Volume:

0.1 mL
Channel Size:

2 µm
Item no.

110.8502-2

Item no.

110.8502-2
CIMac DEAE 0.1 mL Analytical Column (1.3 µm)

Documents
Ligand:

DEAE (weak anion exchanger, diethylamino)
Bed Volume:

0.1 mL
Channel Size:

1.3 µm
Item no.

110.5114-1.3

Item no.

110.5114-1.3
CIMac r-Protein A 0.1 mL Analytical Column (2 µm)

Documents
Ligand:

r-Protein A (affinity, recombinant protein A produced from E. Coli coupled to CDI-preactivated support)
Bed Volume:

0.1 mL
Channel Size:

2 µm
Item no.

110.1004-2

Item no.

110.1004-2
Couldn’t find the product you need?

Tell us what’s missing
CIMac AAV full/empty 0.1 mL Analytical Column (1.3 µm)
Ligand:

QA modified for AAV (strong anion exchanger, quaternary amine)
Bed Volume:

0.1 mL
Channel Size:

1.3 µm
Item no.

110.8503-1.3

Item no.

110.8503-1.3
CIMac Oligo dT18 0.1 mL Analytical Column (C6 Linker) (2 µm)

Documents
Ligand:

Oligo dT18 coupled to CDI-activated matrix, C6 Linker
Bed Volume:

0.1 mL
Channel Size:

2 µm
Item no.

110.1218-2

Item no.

110.1218-2
CIMac PrimaS® 0.1 mL Analytical Column (2 µm)

Documents
Ligand:

PrimaS (multimodal - anion exchange-hydrogen bonding)
Bed Volume:

0,1 mL
Channel Size:

2 µm
Item no.

110.5118-2

Item no.

110.5118-2
CIMac CDI 0.1 mL Analytical Column (1.3 µm)

Documents
Ligand:

CDI (activated; carboxy imidazole)
Bed Volume:

0,1 mL
Channel Size:

1.3 µm
Item no.

110.8000-1.3

Item no.

110.8000-1.3
CIMac r-Protein G 0.1 mL Analytical Column (1.3 µm)

Documents
Ligand:

r-Protein G (affinity, recombinant protein G produced from E. Coli coupled to CDI preactivated support)
Bed Volume:

0.1 mL
Channel Size:

1.3 µm
Item no.

110.1011-1.3

Item no.

110.1011-1.3
Couldn’t find the product you need?

Tell us what’s missing

Results per page: | |

Overview

CIMac Analytical Columns are short-bed high-performance monolithic columns offering all the advantages of CIM^® monolithic technology. Their small volume and short length enable high volumetric flow rates, allowing for the rapid acquisition of quantity and purity information within minutes.

Hence, the CIMac Analytical Columns are ideal for the in-process and final control of various samples from different purification process steps.

Features:

Volume of 0.1 mL (0.3 mL for CIMac pDNA)
Flow rates from 1 to 30 column volumes/minute (varies by type)
Application-optimized channel widths
Available in a wide variety of chemistries

Benefits:

Analytical HPLC columns for nucleic acids, viral vectors, viruses, and other biomolecules
In-process analysis and quantitation, and final product
At-line monitoring and control of manufacturing processes (PAT)
Rapid, high-resolution analysis achieved in minutes
High sensitivity, accuracy and reproducibility
No sample carryover
