The Sartocheck® 5 Plus can perform the following filter integrity tests:
- Bubble Point Test
- Diffusion Test / Forward Flow Test
- Combined Diffusion and Bubble Point Test
- Water Intrusion Test (WIT)
- Pressure Drop Test / Leak Test
Main Features:
Data Integrity:
- Custom Linux-based Operating System
- Four eyes principle with electronic signature
- C10- Internal Double Data Backup
- Encrypted Data
- Time Zone synchronization – NTP
- Audit Trail with time stamped events
- User Matrix to generate individual user roles
- Mandatory fields for Operator entries
- Data entry by Barcode Scanner
- Long-life printouts and sticker function from optional print
Usability:
- Intuitive iF-Design rewarded Human Machine Interface (HMI)
- 12.1" bright touchscreen with a +-88° viewing angle
- Large digital keypad - no need for a pen – compatible with glove use
- 10 system languages
- LDAP - Log on with network user credentials
- Automatic test time for faster testing
- Data transfer
Health, Safety and Environment:
- Splash-proof (IP64)
- Explosion proof (ATEX IECEx & FM certified)
- Safe testing and re-testing of alcohol wetted filters
- Continuous and clear visualization of pressure status
- Resistant to all current cleaning agents
- H2O2-vapor resistant (VHP)
- PFA tubes (FDA 21 CFR 177 and USP Class VI compliant)
- Prepared for automated cleaning of all pneumatics with up to 0.5 M NaOH
- Optional accessory kit for backflow protection
Compliance:
- 21 CFR part 11
- GAMP 5
- Ex proof (ATEX | IECEx | FM)
- CE
- FCC
Supplies:
- Sartocheck 5 Filter Tester
- Inlet and outlet tubes
- Country specific power cable
- Instruction manual
- Network cable 2m
- USB- Cable for the optional printer
- T20 screw driver
