Sartoclean®

Tech Support
Sartoclean®


Sartoclean® family is a cellulose acetate (CA) membrane based prefilter. These filters are optimized for the protection of downstream equipment and Sartobran® cellulose acetate final filters.

Availability:
See more Products below

*Custom/bulk order quotes are provided within 72 hours of request.

Choose your product

Filter by product attributes

Products (146)

  • Sartoclean® GF | 0.65 µm | Sartoscale (PD | Material Screening)
    Documents
    Sartoclean® GF | 0.65 µm | Sartoscale (PD | Material Screening)
    Item no.
    5605305GV--LX--C
    Filter Size
    4.5 cm²
    Item no.
    5605305GV--LX--C
    Filter Size
    4.5 cm²
    Item no.
    5605305GS--FF--M
    Filter Size
    17.3 cm²
  • Sartoclean® GF | 0.8 µm | Sartoscale (PD | Material Screening)
    Documents
    Sartoclean® GF | 0.8 µm | Sartoscale (PD | Material Screening)
    Item no.
    5605304EV--LX--C
    Filter Size
    4.5 cm²
    Item no.
    5605304EV--LX--C
    Filter Size
    4.5 cm²
    Item no.
    5605304ES--FF--M
    Filter Size
    17.3 cm²
  • Sartoclean® CA | 0.8 µm | Sartoscale (PD | Material Screening)
    Documents
    Sartoclean® CA | 0.8 µm | Sartoscale (PD | Material Screening)
    Item no.
    5625304EV--LX--C
    Filter Size
    4.5 cm²
    Item no.
    5625304EV--LX--C
    Filter Size
    4.5 cm²
    Item no.
    5625304ES--FF--M
    Filter Size
    17.3 cm²
  • Sartoclean® CA | 0.65 µm | Sartoscale (PD | Material Screening)
    Documents
    Sartoclean® CA | 0.65 µm | Sartoscale (PD | Material Screening)
    Item no.
    5625305GV--LX--C
    Filter Size
    4.5 cm²
    Item no.
    5625305GV--LX--C
    Filter Size
    4.5 cm²
    Item no.
    5625305GS--FF--M
    Filter Size
    17.3 cm²
  • Sartoclean® GF | 0.65 µm | Cartridge
    Documents
    Sartoclean® GF | 0.65 µm | Cartridge
    Item no.
    5602505G1
    Filter Size
    10"(0.47 m² / 5.1 ft²)
    Adapter
    Bottom: 2-Flange Bayonet w. 226 double o-ring | Top: S-Adapter
    Item no.
    5602505G1
    Filter Size
    10"(0.47 m² / 5.1 ft²)
    Adapter
    Bottom: 2-Flange Bayonet w. 226 double o-ring | Top: S-Adapter
    Item no.
    5602505G2
    Filter Size
    20"(0.94 m² / 10.2 ft²)
    Adapter
    Bottom: 2-Flange Bayonet w. 226 double o-ring | Top: S-Adapter
    Item no.
    5602505G3
    Filter Size
    30"(1.41 m² / 15.3 ft²)
    Adapter
    Bottom: 2-Flange Bayonet w. 226 double o-ring | Top: S-Adapter
  • Sartoclean® GF | 0.65 µm | Maxicaps® (Production | Large Scale)
    Documents
    Sartoclean® GF | 0.65 µm | Maxicaps® (Production | Large Scale)
    Item no.
    5607305G1--SO
    Filter Size
    10"(0.47 m² / 5.1 ft²)
    Type
    Inline (Autoclavable)
    Connector(s)
    Inlet: 1 ½" Sanitary | Outlet: ½" Hose Barb
    Item no.
    5607305G1--SO
    Filter Size
    10"(0.47 m² / 5.1 ft²)
    Type
    Inline (Autoclavable)
    Connector(s)
    Inlet: 1 ½" Sanitary | Outlet: ½" Hose Barb
    Item no.
    5607305G1--OO
    Filter Size
    10"(0.47 m² / 5.1 ft²)
    Type
    Inline (Autoclavable)
    Connector(s)
    Inlet: ½" Hose Barb | Outlet: ½" Hose Barb
    Item no.
    5607305G1--SS
    Filter Size
    10"(0.47 m² / 5.1 ft²)
    Type
    Inline (Autoclavable)
    Connector(s)
    Inlet: 1 ½" Sanitary | Outlet: 1 ½" Sanitary
  • Sartoclean® GF | 0.8 µm | Cartridge
    Documents
    Sartoclean® GF | 0.8 µm | Cartridge
    Item no.
    5602504E1
    Filter Size
    10"(0.47 m² / 5.1 ft²)
    Adapter
    Bottom: 2-Flange Bayonet w. 226 double o-ring | Top: S-Adapter
    Item no.
    5602504E1
    Filter Size
    10"(0.47 m² / 5.1 ft²)
    Adapter
    Bottom: 2-Flange Bayonet w. 226 double o-ring | Top: S-Adapter
    Item no.
    5602504E2
    Filter Size
    20"(0.94 m² / 10.2 ft²)
    Adapter
    Bottom: 2-Flange Bayonet w. 226 double o-ring | Top: S-Adapter
    Item no.
    5602504E3
    Filter Size
    30"(1.41 m² / 15.3 ft²)
    Adapter
    Bottom: 2-Flange Bayonet w. 226 double o-ring | Top: S-Adapter
  • Sartoclean® GF | 0.8 µm | Maxicaps® (Production | Large Scale)
    Sartoclean® GF | 0.8 µm | Maxicaps® (Production | Large Scale)
    Item no.
    5607304E1--OO
    Filter Size
    10"(0.47 m² / 5.1 ft²)
    Type
    Inline (Autoclavable)
    Connector(s)
    Inlet: ½" Hose Barb | Outlet: ½" Hose Barb
    Item no.
    5607304E1--OO
    Filter Size
    10"(0.47 m² / 5.1 ft²)
    Type
    Inline (Autoclavable)
    Connector(s)
    Inlet: ½" Hose Barb | Outlet: ½" Hose Barb
    Item no.
    5607304E1--SS
    Filter Size
    10"(0.47 m² / 5.1 ft²)
    Type
    Inline (Autoclavable)
    Connector(s)
    Inlet: 1 ½" Sanitary | Outlet: 1 ½" Sanitary
    Item no.
    5607304E1--SO
    Filter Size
    10"(0.47 m² / 5.1 ft²)
    Type
    Inline (Autoclavable)
    Connector(s)
    Inlet: 1 ½" Sanitary | Outlet: ½" Hose Barb
  • Sartoclean® CA | 0.8 µm | Cartridge
    Documents
    Sartoclean® CA | 0.8 µm | Cartridge
    Item no.
    5622504E1
    Filter Size
    10"(0.6 m² / 6.5 ft²)
    Adapter
    Bottom: 2-Flange Bayonet w. 226 double o-ring | Top: S-Adapter
    Item no.
    5622504E1
    Filter Size
    10"(0.6 m² / 6.5 ft²)
    Adapter
    Bottom: 2-Flange Bayonet w. 226 double o-ring | Top: S-Adapter
    Item no.
    5622504E2
    Filter Size
    20"(1.2 m² / 12.8 ft²)
    Adapter
    Bottom: 2-Flange Bayonet w. 226 double o-ring | Top: S-Adapter
    Item no.
    5622504E3
    Filter Size
    30"(1.8 m² / 19.3 ft²)
    Adapter
    Bottom: 2-Flange Bayonet w. 226 double o-ring | Top: S-Adapter
  • Sartoclean® CA | 0.65 µm | Cartridge
    Documents
    Sartoclean® CA | 0.65 µm | Cartridge
    Item no.
    5622505G1
    Filter Size
    10"(0.6 m² / 6.5 ft²)
    Adapter
    Bottom: 2-Flange Bayonet w. 226 double o-ring | Top: S-Adapter
    Item no.
    5622505G1
    Filter Size
    10"(0.6 m² / 6.5 ft²)
    Adapter
    Bottom: 2-Flange Bayonet w. 226 double o-ring | Top: S-Adapter
    Item no.
    5622505G2
    Filter Size
    20"(1.2 m² / 12.8 ft²)
    Adapter
    Bottom: 2-Flange Bayonet w. 226 double o-ring | Top: S-Adapter
    Item no.
    5622505G3
    Filter Size
    30"(1.8 m² / 19.3 ft²)
    Adapter
    Bottom: 2-Flange Bayonet w. 226 double o-ring | Top: S-Adapter
  • Sartoclean® CA | 0.65 µm | Maxicaps® (Production | Large Scale)
    Sartoclean® CA | 0.65 µm | Maxicaps® (Production | Large Scale)
    Item no.
    5627305G1--SS
    Filter Size
    10"(0.6 m² / 6.5 ft²)
    Type
    Inline (Autoclavable)
    Connector(s)
    Inlet: 1 ½" Sanitary | Outlet: 1 ½" Sanitary
    Item no.
    5627305G1--SS
    Filter Size
    10"(0.6 m² / 6.5 ft²)
    Type
    Inline (Autoclavable)
    Connector(s)
    Inlet: 1 ½" Sanitary | Outlet: 1 ½" Sanitary
    Item no.
    5627305G1--OO
    Filter Size
    10"(0.6 m² / 6.5 ft²)
    Type
    Inline (Autoclavable)
    Connector(s)
    Inlet: ½" Hose Barb | Outlet: ½" Hose Barb
    Item no.
    5627305G1--SO
    Filter Size
    10"(0.6 m² / 6.5 ft²)
    Type
    Inline (Autoclavable)
    Connector(s)
    Inlet: 1 ½" Sanitary | Outlet: ½" Hose Barb
  • Sartoclean® CA | 0.8 µm | Maxicaps® (Production | Large Scale)
    Sartoclean® CA | 0.8 µm | Maxicaps® (Production | Large Scale)
    Item no.
    5627304E1--SS
    Filter Size
    10"(0.6 m² / 6.5 ft²)
    Type
    Inline (Autoclavable)
    Connector(s)
    Inlet: 1 ½" Sanitary | Outlet: 1 ½" Sanitary
    Item no.
    5627304E1--SS
    Filter Size
    10"(0.6 m² / 6.5 ft²)
    Type
    Inline (Autoclavable)
    Connector(s)
    Inlet: 1 ½" Sanitary | Outlet: 1 ½" Sanitary
    Item no.
    5627304E1--OO
    Filter Size
    10"(0.6 m² / 6.5 ft²)
    Type
    Inline (Autoclavable)
    Connector(s)
    Inlet: ½" Hose Barb | Outlet: ½" Hose Barb
    Item no.
    5627304E1--SO
    Filter Size
    10"(0.6 m² / 6.5 ft²)
    Type
    Inline (Autoclavable)
    Connector(s)
    Inlet: 1 ½" Sanitary | Outlet: ½" Hose Barb
  • Sartoclean® GF | 0.8 µm | Midicaps® (Production | Small Scale)
    Documents
    Sartoclean® GF | 0.8 µm | Midicaps® (Production | Small Scale)
    Item no.
    5605304E0--SO--V
    Filter Size
    size 0 (0.32 m² / 3.4 ft²)
    Item no.
    5605304E0--SO--V
    Filter Size
    size 0 (0.32 m² / 3.4 ft²)
    Item no.
    5605304E0--SS--V
    Filter Size
    size 0 (0.32 m² / 3.4 ft²)
    Item no.
    5605304E0--OO--V
    Filter Size
    size 0 (0.32 m² / 3.4 ft²)
  • Sartoclean® GF | 0.65 µm | Midicaps® (Production | Small Scale)
    Documents
    Sartoclean® GF | 0.65 µm | Midicaps® (Production | Small Scale)
    Item no.
    5605305G0--SO--V
    Filter Size
    size 0 (0.32 m² / 3.4 ft²)
    Item no.
    5605305G0--SO--V
    Filter Size
    size 0 (0.32 m² / 3.4 ft²)
    Item no.
    5605305G0--OO--V
    Filter Size
    size 0 (0.32 m² / 3.4 ft²)
    Item no.
    5605305G0--SS--V
    Filter Size
    size 0 (0.32 m² / 3.4 ft²)
  • Sartoclean® CA | 0.8 µm | Midicaps® (Production | Small Scale)
    Sartoclean® CA | 0.8 µm | Midicaps® (Production | Small Scale)
    Item no.
    5625304E0--SO--V
    Filter Size
    size 0 (0.45 m² / 4.8 ft²)
    Item no.
    5625304E0--SO--V
    Filter Size
    size 0 (0.45 m² / 4.8 ft²)
    Item no.
    5625304E0--OO--V
    Filter Size
    size 0 (0.45 m² / 4.8 ft²)
    Item no.
    5625304E0--SS--V
    Filter Size
    size 0 (0.45 m² / 4.8 ft²)
Results per page: | |

Applications:

  • Vaccines and Blood & Plasma
  • Protection of downstream equipment and CA final membrane filters
  • Bioburden reduction

Benefits:

  • Highest product yields
  • Ultra-low unspecific binding membrane
  • More economical process flow
  • Increased total throughput performance

Pure CA Membrane
Sartoclean® CA

Two variants are available. Either a heterogeneous double layer for highest protection and total throughput performance (3.0 µm|0.8 µm or 0.8 µm|0.65 µm combination) or single layer (0.45 µm or 0.2 µm) membrane constellation for highest flow rates.

Power of glass fleece
Sartoclean® GF

The heterogeneous double layer (3.0 µm|0.8 µm or 0.8 µm|0.65 µm combination) is protected by a layer of glass fleece. This increased the total throughput performance of the membrane double layer and adds an adsorptive component to your filtration process.

For highest process flexibility all Sartoclean® filters are available for conventional or single use applications. All filter elements are available in various sizes and adapter combinations. Review the selection guide in our supporting resources literature.

Product Information

  • Brand
    Sartoclean®
